Documentation for midas_fw_view

Name	FilmAgent
Used by (from the same schema document)	Element Credits
Type	Locally-defined complex type
Nillable	no
Abstract	no
Documentation	FilmAgent models rather the identity of a physical person.

XML Instance Representation

<Function> ... </Function> [0..1]

<CharacterName> ... </CharacterName> [0..1]

<AgentName
uid=" Guid [1]"
origin=" xs:string [1]"
localid=" xs:string [0..1]"
preferredName=" xs:string [0..1]"> [1]

'AgentName models the idea of aliases of artists. Thus it is possible to reference to a physical person with several aliases.'

xs:string
</AgentName>

</FilmAgent>

Schema Component Representation

<xs:element name="FilmAgent">

<xs:complexType>

<xs:sequence>

<xs:element ref=" Function " minOccurs="0"/>

<xs:element ref=" CharacterName " minOccurs="0"/>

<xs:element name="AgentName">

<xs:complexType>

<xs:simpleContent>

<xs:extension base=" xs:string ">

<xs:attribute name="uid" type=" Guid " use="required"/>

<xs:attribute name="origin" type=" xs:string " use="required"/>

<xs:attribute name="localid" type=" xs:string " use="optional"/>

<xs:attribute name="preferredName" type=" xs:string " use="optional"/>

</xs:extension>

</xs:simpleContent>

</xs:complexType>

</xs:element>

</xs:sequence>

<xs:attribute name="uid" type=" Guid " use="required"/>

<xs:attribute name="agentType" type=" xs:string " use="required"/>

<xs:attribute name="origin" type=" xs:string " use="required"/>

<xs:attribute name="localid" type=" xs:string " use="optional"/>

</xs:complexType>

</xs:element>
